MDF/HDF Production Line Board Machinery Multi Opening Press 4x12ft
-
Highlight
MDF/HDF board machinery
,MDF/HDF Production Line
,Multi Opening Press 4x12ft
-
Place of OriginChina
-
Brand NameSufoTech
-
Minimum Order Quantity1
-
PriceUSD+1,000,000.00~3,000,000.00
-
Packaging DetailsWooden package
-
Delivery Time10 months
-
Payment TermsT/T, L/C
MDF/HDF Production Line Board Machinery Multi Opening Press 4x12ft
4x12ft Fully Automatic MDF/HDF Multi-Opening Line 100-700m³/day
Fully Automatic 100~700 Cbm Per Day MDF/HDF Multi-Opening Press Production Line
Description
The 180-700m³/day MDF/HDF production line uses raw material through chips preparation, fiber manufacturing, glue dosing system, forming and hot pressing, cooling &trimming and sanding section to make MDF/HDF board. The final size can be 4 x 8, 6 x 8, 6 x 9, 4 x 12, 6 x 12, 6 x 18. The MDF/HDF board has homogeneous structure, smooth surface, good machining specification and manufacture performance. It is the ideal substitute of nature wood.
Optional Accessories:
Light curtains
Pressure strips
Remote system monitoring
Remote diagnostics
Die tables
Die loaders
Die clamping
Die storage
Local or centralized controls
Summary of process flow
- Chips Preparation Section
- Fiber Preparation Section
- Glue Dosing System
- Drying Section
- Forming and Hot Press section
- Sanding and Cutting Line
Main technical data
| Item | Unit | Specification |
| Capacity | m³/d | 100~700 |
| Width of production line | feet | 4,6 |
| Final board thickness | mm | 8~30 |
| Final board width | mm | 915~1830 |
| Final board length | mm | 1830~5490 |
| Press Layers | daylight | Max. 32 |
Key equipment of production line
- Drum chipper
- Refiner
- Forming line
- Hot press
- Sanding line
